Condenser, externally polarized |
Pressure gradient transducer |
3 micron gold sputtered Mylar |
25.4 mm, 1 in |
Omni, wide cardioid, cardioid, supercardioid, figure-8, reverse cardioid, reverse wide cardioid, reverse supercardioid |
20 ... 20,000 Hz |
17.2 mV/Pa, -35.3 dBV/Pa |
7 dB (A) |
144 dBSPL |
87 dB (A) |
137 dB (A) |
48 V ± 4 V |
4 mA |
54 Ω |
Gold plated 3-pin XLR |
Zinc die cast |
Microphones measured according to: IEC 60268-4 | Phantom power according to: IEC 61938 | Noise measurement according to: IEC 60268-1
